Triaxial Strength

Since in actual conditions, the rocks are under triaxial stress, determine their position in these conditions it is important to calculate the bearing capacity of the rocks, dam design, studying the mechanism of creating faults and folding and underground excavation. By performing this test, the rock fracture is drawn and determined parameters, based on the resistance of the rock.

The researchers by using this test found that fracture failure is not only a mechanism for rock failure but many of the stones in the high side pressure they show a very completely flexible behavior. There are different methods for performing a triaxial test, in which, different instruments, how to perform and measurement is different. The simplest and most common method of obtaining triaxial stress in the laboratory, apply side pressure hydraulic with axial stress to cylindrical sample.

To perform this test, the following equipment is required:

  1. Pressure compression jack is to apply vertical pressure that is normally used with concrete breaker jack.
  2. A tri-axial or Hoek Cell that is made in different sizes.
  3. Hand-operated hydraulic pump for applying side pressure.
Standards:
ASTM D2664, D2938, D3148, D5407

  • No_Image_Available_1

Equipment required for testing:

Ordering Code

Description

Sample Size
Dimensions
Aprrox
Weight
Material
SMRO-1210
Rock Triaxial Cell
(Hoek cell)
Size: 54
Ø54 mm
...
...
...
SMRO-1220
Rock Triaxial Cell
(Hoek cell)
Size: 61.7
Ø61.7 mm
...
...
...
SMRO-1230
Rock Triaxial Cell
(Hoek cell)
Size: 71.7
Ø71.7 mm
...
...
...
SMRO-1240
Rock Triaxial Cell
(Hoek cell)
Size: 83.7
Ø83.7 mm
...
...
...

Description

  1. All cells have two caps dipped outer for easy opening and closing.
  2. All the cells have one rubber membrane based on the size of the sample.
  3. All the cells have two vents to insert oil pressure and the other for evacuation.
  4. All the cells have a fitting connection for easy to attach to the hydraulic jack.
  5. All cells have the ability to withstand side pressure up to 70 MPa
  6. All the cells have two adapters for apply force vertically

Ordering Code

Description

Pressure Range
Dimensions
Aprrox Weight
Mechanism
SMRO-1310
Hand-operated
Pressure System
0-70 MPa
...
...
Hydraulic
and
Manual
