Oven
Another commonly used device in the geotechnical lab and materials resistance is an oven (it or oven) that works in the laboratory to dry soil samples, concrete, asphalt, cement, etc.
Unlike hotplates, they have a closed stainless steel enclosure (albeit in high-quality models) to transfer heat to the sample, the laboratory sample is placed inside the enclosure and its temperature rises. To this end, the oven is fitted with the desired capacity and according to the size of the work to the buyer's choice.
| Description | Digital Oven Model OD.53
| Digital Oven Model OD.115 | Digital Oven Model OD.240 | Digital Oven Model OD.250 |
|---|---|---|---|---|
|
Ordering Code
|
SMGE-4310
|
SMGE-4320
|
SMGE-4350
|
SMGE-4355
|
|
Useful volume
Lit |
53 |
115
|
240
|
250
|
|
Temperature range
°C
|
50-240
|
50-240 | 50-240 |
50-200
|
|
Power Supply
|
220V, 50Hz, 800W, 3.6A
|
220V, 50Hz, 1600W, 7.5A
|
220-380V, 50Hz, 4500W, 7A
|
220V, 50Hz, 2000W, 9A
|
|
Maximum heating
time at 20 °C without load |
45 min
|
45 min |
|
|
|
Maximum time
to achieve temperature stability |
|
2 h
|
2 hح
|
|
| Maximum thermal equilibrium at 100 °C |
2 °C
|
2 °C | 2 °C |
2 °C
|
|
Digital thermostat
|
0-240 °C
|
0-250 °C
|
0-240 °C
|
0-250 °C
|
|
Thermostat gradation
|
1 °C
|
1 °C
|
1 °C
|
1 °C
|
|
Net weight
|
24 Kg |
95 Kg
|
170 Kg
|
104 Kg
|
|
Internal dimensions
D×W×H
|
33×40×40 Cm
|
40×60×48 Cm | 50×60×80 Cm |
60×65×65 Cm
|
|
Dimensions
L×W×H
|
52×51×68 Cm
|
70×64×128 Cm
|
70×84×130 Cm
|
78×76×90 Cm
|
|
Heating element
|
KANTAL A1, wide network at all levels
|
KANTAL A1, U shape in all levels
|
In the form of a bar
|
|
|
External material
|
Stainless Steel Sheets and Galvanized Sheets | Iron Sheets | ||
|
The inner
chamber material |
Stainless Steel Sheets or Aluminium Sheets
|
Opaque and resistant steel
|
||
| Number of floors |
2 floors and 2 stainless steel trays
|
4 floors and 4 stainless steel trays
|
2 floors and 2 stainless steel trays
|
|
|
Insulation
|
Rock wool insulation of 5 cm
|
|||
|
Color
|
Corrosion resistant furnace color
|
|||
