Cement Mixer
Cement paste and mortar mixer for mixing water and cement in specified ratio it’s design and built in order to supply the needs of the standard are presented below. This heavy-duty mixer has two operating speed and reservoir with capacity of 5 liters. The blade of mixer it has a planetary motion this means that not only the blade rotates around its axis but also blade rotate around the motor shaft.
|
Standards:
|
BS 3892-1, 3892-3, 6463-103, 4551-1, EN 196-1, 196-3, 413-2, 459-2, 1744-1, 13279-2, 1015-2, 13395-1, 13454-2
|
Specifications:
|
Ordering Code: |
SMCE-7100 |
|
| Dimension: |
60×38×65 Cm ( L×W×H )
|
|
|
Weight:
|
85 Kg
|
|
|
Power Supply:
|
220 V, 50 Hz, 1 ph
|
|
|
Speed:
|
Paddle
|
Head
|
|
Max
|
140±5 rpm
|
62±5 rpm
|
|
Min
|
285±10 rpm
|
125±10 rpm
|
